IBC Tote Pump W/48″ Stainless Steel Tube, 3/4 HP Air Motor, 15,000 Cps, 7 Gpm (HVDP Series)

This air motor tote pump has a 2″ Dia. x 48″ stainless steel tube, a max flow of 7 gpm and max viscosity of 15,000 cps. This low reduction IBC tote pump is ideal for transferring high viscosity materials up to 180° F as it features a progressive cavity design. A planetary gear set reducer allows this pump to provide a smooth and non-pulsating flow. Typical applications include paints, adhesives, oils, etc. in the chemical and coatings industries. The max specific gravity is 1.80.

The air motor is non-electric and thus has a reduced possibility of explosion from igniting flammable material or combustibles during use allowing the motor to be a safer alternative than standard electric motors. Tote pumps can provide container-to-container liquid transfer when the tote is too heavy to lift. The 316 stainless steel tube is 48″ for use with IBC totes and other similar-sized containers. Stainless steel is ideal for more flammable such as solvents compared to plastic alternatives. The discharge connection is larger than traditional tote pumps and is a 2″ hose barb for high viscosity liquids. This tote pump offers quick disassembly for ease of cleaning due to its unique camlock feature.

Key benefits:

• Explosion proof pneumatic air motor
• 316 stainless steel tube
• 4:1 speed reducer
• Buna stator material
• For use with containers with less than 48″ depth
• Suitable for high viscosity liquids
• For use up to 180° F | 82° C
• Max flow 7 gpm
